Specifications
Overall Length – Foot Section Extended: 94 ½” (240 cm)
Overall Length – Foot Section Retracted: 82 ½” (210 cm)
Maximum Width (siderails stored): 37” (94 cm)
Maximum Width (siderails up): 40” (102 cm)
Maximum Headboard Height: 39 ½” (100 cm)
Mattress to Siderail Height: 9 ½” (24 cm)
Minimum Under-Bed Clearance: 3” (8 cm) 1 ¼” (3.18 cm)
IntelliDrive® Transport System bedsWheel Base: 26 ¾” x 62” (67.95 cm x 157.48 cm)
Surface Dimensions: 35 ½” x 86 2/5’’ (90 cm x 219.5 cm)
Caster Size: 5” (13 cm) standard, or 6” (15 cm) optional (standard on IntelliDrive® Transport System beds)
Bed Lift Capacity (safe working load) (includes patient weight, mattress, IV poles, and such): 550 lb. (249 kg)
Total Weight without Surface: 495 lb. (224 kg)
Head Section Inclination (maximum): 65°
Knee Section Inclination (maximum): 16°
Foot Section Inclination (maximum): -27°
